Triumph Tiger 1200 Explorer XC 2016 - Technical motorcycle description

Tell us what you think of this Tiger 1200 Explorer XC 2016

Une moto Triumph Tiger 1200 Explorer XC de 2016

Specifications Triumph Tiger 1200 Explorer XC 2016

Chassis: Two-seater saddle; Frame : Tubular steel mesh; Fuel capacity : 20 liters (5.28 US gallons); Oil capacity : 4 liters (1.06 US gallons); seat height adjustable between 837 mm and 857 mm; Width : 830 mm (32.68 in); Min height : 1,400 mm (55.12 in); Wheelbase : 1,520 mm (59.84 in); Dry weight : 244 kg (538 lb)

Front axle: Reverse telehydraulic fork Ø 48 mm / White Power (WP), Wheel travel : 190 mm (7.48 in); Angle de chasse : 23.1 °; Preload adjustment; Braking 2 Brembo discs Ø 305 mm (12.01 in), radial mounting, 4-piston caliper; Front tire (Tubeless) : 120 / 70 - 19 → Order this type of tire; Pressure : 2.2 bar

Transmission: 6 stage gearbox , manual; Secondary cardan shaft

Rear axle: Monoshock / White Power (WP), Wheel travel : 196 mm (7.72 in); Preload, compression and rebound adjustment; Braking 1 Nissin disc Ø 282 mm (11.1 in); Rear tire (Tubeless) : 170 / 60 - 17 → Order this type of tire; Pressure : 2.7 bar

Motor: 3 cylinders online , 4 strokes; Injection Ø nc; Cooling system : liquid; 2 ACT; 4 valves per cylinder; 1,215 cc; 139 ch (137.10 hp) to 9,300 rpm; 12.50 mkg (123 Nm) to 6,200 rpm; Power-to-weight ratio : 1.78 kg/ch; Weight / torque ratio : 19.52 kg/mkg; Compression : 11 : 1; Starting system : electric

Standard equipment: Brake assist : ABS; Number of riding modes : 2; Traction control; Center stand; Electric adjustable windscreen; Gear indicator; Spoke wheels; USB plug; 12V socket; Adjustable seat; Mono Swingarm; Engine Guard

Practical information

Take care of your motorcycle! Find all the parts and maintenance products you need to keep your bike in top condition.

motor fluid exhaust Chain kit electricity filtration braking Tires

Essentials

Motorcyle equipment adapted for all members of the family and security elements.

Trouvez votre casque

Trouvez des gants

Trouver un intercom

Motoblouz

Augmenter sa sécurité avec un airbag

Maxxess

Motoblouz

LaBécanerie

Speedway

Trouvez votre blouson

Motorcyle equipment adapted for all members of the family and security elements.

presentation

The basic version of the Triumph 1200 Tiger Explorer, the XC version was only marketed in the UK.

Gallery

Key facts Triumph Tiger 1200 Explorer XC (2016) : What you need to know before you buy

Prices

	Basic version
United Kingdom	£12,200

Bikers' reviews

of 0 review Read reviews

Model sold in 2016

Replace 1200 TIGER EXPLORER XC 2015

1200 TIGER EXPLORER XC 2015

Performance

Max speed : over 200 km/h (124.30 mph)

Models

2016

Competitors

Honda CRF 1000 L AFRICA TWIN 2016

BMW R 1200 GS 2016

Ducati Multistrada 1200 Enduro 2016

KTM 1190 Adventure R 2016

Yamaha XTZ 1200 Super Ténéré 2016

Moto-Guzzi STELVIO 1200 8V NTX 2016

Aprilia 1200 CAPONORD RALLY 2016

Find others On-Off Road of 2016

Compare the Tiger 1200 Explorer XC to its competitors

Acceleration

Triumph Tiger 1200 Explorer XC 2016 Undisclosed

Honda CRF 1000 L AFRICA TWIN 2016 Undisclosed

BMW R 1200 GS 2016 : 3.6 s

Ducati Multistrada 1200 Enduro 2016 Undisclosed

KTM 1190 Adventure R 2016 Undisclosed

Yamaha XTZ 1200 Super Ténéré 2016 Undisclosed

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 3.9 s

Aprilia 1200 CAPONORD RALLY 2016 Undisclosed

Fuel consumption

Triumph Tiger 1200 Explorer XC 2016 Undisclosed

Honda CRF 1000 L AFRICA TWIN 2016 : 4.60 liters/100km (0.51 mpg)

BMW R 1200 GS 2016 : 5.50 liters/100km (0.43 mpg)

Ducati Multistrada 1200 Enduro 2016 : 5.60 liters/100km (0.42 mpg)

KTM 1190 Adventure R 2016 Undisclosed

Yamaha XTZ 1200 Super Ténéré 2016 Undisclosed

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 7 liters/100km (0.34 mpg)

Aprilia 1200 CAPONORD RALLY 2016 Undisclosed

Range

Triumph Tiger 1200 Explorer XC 2016 Undisclosed

Honda CRF 1000 L AFRICA TWIN 2016 : 409 km (254 miles)

BMW R 1200 GS 2016 : 364 km (226 miles)

Ducati Multistrada 1200 Enduro 2016 : 536 km (333 miles)

KTM 1190 Adventure R 2016 Undisclosed

Yamaha XTZ 1200 Super Ténéré 2016 Undisclosed

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 457 km (284 miles)

Aprilia 1200 CAPONORD RALLY 2016 Undisclosed

Torque

Triumph Tiger 1200 Explorer XC 2016 : 12.5 mkg

Honda CRF 1000 L AFRICA TWIN 2016 : 10 mkg

BMW R 1200 GS 2016 : 12.7 mkg

Ducati Multistrada 1200 Enduro 2016 : 13.9 mkg

KTM 1190 Adventure R 2016 : 12.7 mkg

Yamaha XTZ 1200 Super Ténéré 2016 : 11.9 mkg

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 11.2 mkg

Aprilia 1200 CAPONORD RALLY 2016 : 11.7 mkg

Power

Triumph Tiger 1200 Explorer XC 2016 : 139 ch (137.10 hp)

Honda CRF 1000 L AFRICA TWIN 2016 : 95 ch (93.70 hp)

BMW R 1200 GS 2016 : 125 ch (123.30 hp)

Ducati Multistrada 1200 Enduro 2016 : 160 ch (157.80 hp)

KTM 1190 Adventure R 2016 : 150 ch (147.90 hp)

Yamaha XTZ 1200 Super Ténéré 2016 : 112 ch (110.50 hp)

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 102 ch (100.60 hp)

Aprilia 1200 CAPONORD RALLY 2016 : 125 ch (123.30 hp)

Power-to-Weight ratio

Triumph Tiger 1200 Explorer XC 2016 : 1.78 kg/ch

Honda CRF 1000 L AFRICA TWIN 2016 : 2.26 kg/ch

BMW R 1200 GS 2016 : 1.79 kg/ch *

Ducati Multistrada 1200 Enduro 2016 : 1.5 kg/ch

KTM 1190 Adventure R 2016 : 1.47 kg/ch

Yamaha XTZ 1200 Super Ténéré 2016 : 2.15 kg/ch *

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 2.53 kg/ch

Aprilia 1200 CAPONORD RALLY 2016 Undisclosed

Torque-to-Weight ratio

Triumph Tiger 1200 Explorer XC 2016 : 19.52 kg/mkg

Honda CRF 1000 L AFRICA TWIN 2016 : 21.2 kg/mkg

BMW R 1200 GS 2016 : 17.39 kg/mkg *

Ducati Multistrada 1200 Enduro 2016 : 16.98 kg/mkg

KTM 1190 Adventure R 2016 : 17.09 kg/mkg

Yamaha XTZ 1200 Super Ténéré 2016 : 19.97 kg/mkg *

Moto-Guzzi STELVIO 1200 8V NTX 2016 : 22.77 kg/mkg

Aprilia 1200 CAPONORD RALLY 2016 Undisclosed

Speed

Triumph Tiger 1200 Explorer XC 2016 : over 200 km/h (124.30 mph)

Honda CRF 1000 L AFRICA TWIN 2016 : approximately 200 km/h (124.30 mph)

BMW R 1200 GS 2016 : 200 km/h (124.30 mph)

Ducati Multistrada 1200 Enduro 2016 Undisclosed

KTM 1190 Adventure R 2016 : 220 km/h (136.70 mph)

Yamaha XTZ 1200 Super Ténéré 2016 : approximately 200 km/h (124.30 mph)

Moto-Guzzi STELVIO 1200 8V NTX 2016 : approximately 200 km/h (124.30 mph)

Aprilia 1200 CAPONORD RALLY 2016 : approximately 200 km/h (124.30 mph)

filter and compareother models

Bikers' reviews Leave a review

Used

Find this used Tiger 1200 Explorer XC on MotoPlanete

TIGER 1200 EXPLORER 2016

8990€

Find the motorcycle that fits your lifestyle. Browse our inventory of used motorcycles.

FAQ Your frequently asked questions about the Tiger 1200 Explorer XC 2016

What is the power of the Tiger 1200 Explorer XC?: The Tiger 1200 Explorer XC 2016 develops a power of 139 ch (137.10 hp)
What is the torque of the Tiger 1200 Explorer XC?: The maximum torque of the Tiger 1200 Explorer XC 2016 is 12.50 mkg (123 Nm) to 6,200 rpm.
What is the maximum speed of the Tiger 1200 Explorer XC?: The Tiger 1200 Explorer XC 2016 is capable of reaching a top speed of over 200 km/h (124.30 mph) on the track.
What is the weight of the Tiger 1200 Explorer XC?: The Tiger 1200 Explorer XC 2016 has a a dry weight of 244 kg (538 lb).
QWhat is the seat height of the Tiger 1200 Explorer XC?: To ensure good accessibility, the Tiger 1200 Explorer XC 2016 offers a minimum seat height of 837 mm (32.95 in). The integrated adjustment allows you to adjust the riding position to suit your needs.
What is the price of the Tiger 1200 Explorer XC?: The price of the Tiger 1200 Explorer XC 2016 is £12,200 in United Kingdom
What size tires should I put on my Tiger 1200 Explorer XC?: The standard size for a Tiger 1200 Explorer XC 2016 is 120 / 70 - 19 for the front, and 170 / 60 - 17 for the rear.
What colors are available for the Tiger 1200 Explorer XC?: For the 2016 model year, the Tiger 1200 Explorer XC is available in one color: black.
